RDR-623 - Low Standby Current, Non-Isolated Flyback Power Supply Using LinkSwitch-TN2
Low Standby Current, Non-Isolated Flyback Power Supply Using LinkSwitch-TN2 (LNK3202D)
Applications
Specifications
Design Type
Reference Design Reports (RDR)
Topology
Flyback
Vout 1
3.80 V
Vout 2
12.00 V
Vin (min)
85
Vin (max)
277
CV/CC
CV
Efficiency
85.00%
Isolated?
No
Number of outputs
2
Associated Parts
LNK3202D
Gerber File
rd623gerber.zip
