DER-515 - 12 W Non-Dimmable Non-Isolated LED Driver
Applications
Specifications
Design Type
Design Example Reports (DER)
Topology
Buck-Boost
Vout 1
72.00 V
Vin (min)
90
Vin (max)
308
TRIAC dimmable?
No
CV/CC
CC
Efficiency
89.00%
Isolated?
No
Number of outputs
1
Output Power
12.00 W
Associated Parts
LYT5226D
Gerber File
rd515gerber.zip
