DER-423 - 12 W Power Factor Corrected (Valley Fill) Non-Dimmable Isolated LED Driver

View PDF Download PDF

Notify Me of Updates

Applications

Products

Specifications

Design Type Design Example Reports (DER)

Topology Flyback

Vout 1 24.00 V

Vin (min) 190

Vin (max) 265

TRIAC dimmable? No

CV/CC CV

Efficiency 80.00%

Isolated? Yes

Number of outputs 1

Output Power 12.00 W

OVP? Yes

PFC? Yes

Associated Parts TNY286PG

Gerber File rd423gerber.zip
