DER-214 - 2.25 W Low Cost Cooktop Controller
Applications
Specifications
Design Type
Design Example Reports (DER)
Topology
Flyback
RoHS?
Yes
Vout 1
9.00 V
Vin (min)
175
Vin (max)
265
CV/CC
CV
Isolated?
Yes
Number of outputs
1
Output Power
2.25 W
Associated Parts
LNK623PG
Gerber File
rd214gerber.zip
